LM3886TF/NOPB
RoHS
RoHS compliant
RoHS compliantPackage TO-220-11 Isolated Tab, Formed Leads
Category Integrated Circuits (ICs) / Linear - Amplifiers - Audio
Description
EAR99 LM3886 Tube Mute Short-Circuit and Thermal Protection audio amplifier 10mV 4.496mm 68W x 1 @ 4Ohm 11.5A
PDF
/
Buying Options
Total Price: USD $6.56
Unit Price: USD $6.5648
≥1 USD $6.5648
≥10 USD $5.9268
≥100 USD $5.65114
≥500 USD $4.906792
≥1000 USD $4.686238
≥3000 USD $4.272752
Inventory: 1261
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Thickness 4.496mm
Width 19.583mm
Length 20.015mm
Height 4.62mm
Technical
Load Impedance 4 Ω
Max Output Power x Channels @ Load 68W x 1 @ 4 Ω
Input Bias Current 1μA
Min Dual Supply Voltage 10V
Max Output Power 68W
Max Dual Supply Voltage 42V
Gain 3 dB
Power Supply Rejection Ratio (PSRR) 120dB
Voltage Gain 115dB
Gain Bandwidth Product 8MHz
Bandwidth 3MHz
Input Offset Voltage (Vos) 10mV
Supply Type Dual, Single
Common Mode Rejection Ratio 85 dB
Output Power 68W
Supply Current-Max 85mA
Quiescent Current 50mA
Output Current 11.5A
Power Dissipation 125W
Number of Channels 1
Max Output Current 11.5A
Output Type 1-Channel (Mono)
Pin Count 3
Base Part Number LM3886
Time@Peak Reflow Temperature-Max (s) 40
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position ZIG-ZAG
Voltage - Supply 20V~84V ±10V~42V
Technology BIPOLAR
Max Power Dissipation 125W
Subcategory Audio/Video Amplifiers
Type Class AB
ECCN Code EAR99
Number of Terminations 11
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Mute, Short-Circuit and Thermal Protection
JESD-609 Code e3
Series Overture?
Packaging Tube
Operating Temperature -20°C~85°C TA
Physical
Weight 13.607771g
Number of Pins 11
Surface Mount NO
Package / Case TO-220-11 Isolated Tab, Formed Leads
Mounting Type Through Hole
Contact Plating Tin
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 8 Weeks
