LM1876TF
RoHS
/
Package TO-220-15 Isolated Tab, Formed Leads
Category Integrated Circuits (ICs) / Linear - Amplifiers - Audio
Description
Non-RoHS Compliant Contains Lead Through Hole Obsolete Amplifier IC Class AB 4Ohm -20C~85C TA 7.5MHz 80dB
PDF
/
Buying Options
Total Price: USD $4.98
Unit Price: USD $4.97705
≥1 USD $4.97705
≥10 USD $4.08405
≥100 USD $3.95675
≥500 USD $3.8285
≥1000 USD $3.7012
Inventory: 25006
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Technical
Load Impedance 4Ohm
Number of Amplifiers 2
Harmonic Distortion 0.009%
Max Output Power x Channels @ Load 22W x 2 @ 4 Ω
Input Bias Current 500nA
Dual Supply Voltage 28V
Min Dual Supply Voltage 10V
Max Output Power 22W
Max Dual Supply Voltage 32V
Power Supply Rejection Ratio (PSRR) 115dB
Voltage Gain 110dB
Gain Bandwidth Product 7.5MHz
Bandwidth 7.5MHz
Input Offset Voltage (Vos) 15mV
Supply Type Dual, Single
Common Mode Rejection Ratio 80 dB
Output Power 20W
Supply Current-Max 80mA
Power Dissipation 62.5W
Number of Channels 2
Operating Supply Voltage 28V
Output Type 2-Channel (Stereo)
Pin Count 3
Base Part Number LM1876
Number of Functions 1
Terminal Position ZIG-ZAG
Voltage - Supply 20V~64V ±10V~32V
Technology BIPOLAR
Max Power Dissipation 62.5W
Subcategory Audio/Video Amplifiers
Terminal Finish Tin/Lead (Sn/Pb)
Type Class AB
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
Feature Depop, Mute, Short-Circuit and Thermal Protection
JESD-609 Code e0
Series Overture?
Packaging Tube
Operating Temperature -20°C~85°C TA
Physical
Number of Pins 15
Surface Mount NO
Package / Case TO-220-15 Isolated Tab, Formed Leads
Mounting Type Through Hole
