INA137UA/2K5G4
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Audio
Description
GULL WING ROHS3Compliant Lead Free Surface Mount Amplifier IC Class AB 24kOhm 14V/mus -40C~85C TA 74dB
PDF
/
Buying Options
Total Price: USD $2.15
Unit Price: USD $2.1489
≥1 USD $2.1489
≥10 USD $1.7632
≥100 USD $1.7081
≥500 USD $1.653
≥1000 USD $1.5979
Inventory: 1724
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 1.58mm
Width 3.91mm
Length 4.9mm
Height 1.75mm
Technical
Min Dual Supply Voltage 4V
Max Dual Supply Voltage 18V
Voltage Gain 6.021dB
Neg Supply Voltage-Nom (Vsup) -18V
Input Offset Voltage (Vos) 1mV
Common Mode Rejection Ratio 74 dB
Slew Rate 14 V/μs
Input Voltage (Min) 8V
Quiescent Current 2.4mA
Number of Channels 1
Number of Elements 2
Operating Supply Voltage 28V
Output Type 1-Channel (Mono)
Pin Count 8
Base Part Number INA137
Supply Voltage 18V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply ±4V~18V
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Resistance 24kOhm
Type Class AB
Number of Terminations 8
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Weight 75.891673mg
Number of Pins 8
Surface Mount YES
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 6 Weeks
