TS4998IQT
RoHS
RoHS compliant
RoHS compliantPackage 16-VQFN Exposed Pad
Category Integrated Circuits (ICs) / Linear - Amplifiers - Audio
Description
EAR99 TS4998 Tape & Reel (TR) Depop Differential Inputs Standby Thermal Protection audio amplifier 5V 4mm 1W x 2 @ 8Ohm 7.4mA
PDF
/
Buying Options
Total Price: USD $0.81
Unit Price: USD $0.8056
≥1 USD $0.8056
≥10 USD $0.6612
≥100 USD $0.6403
≥500 USD $0.62035
≥1000 USD $0.59945
Inventory: 1372
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 16-VQFN Exposed Pad
Number of Pins 8
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Feature Depop, Differential Inputs, Standby, Thermal Protection
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
ECCN Code EAR99
Type Class AB
Subcategory Audio/Video Amplifiers
Voltage - Supply 2.7V~5.5V
Terminal Position QUAD
Number of Functions 1
Terminal Pitch 0.65mm
Base Part Number TS4998
Pin Count 16
JESD-30 Code S-XQCC-N16
Output Type 2-Channel (Stereo)
Operating Supply Voltage 5V
Number of Channels 2
Nominal Supply Current 7.4mA
Output Power 1W
Common Mode Rejection Ratio 57 dB
Supply Type Single
Bandwidth 20 kHz
Gain Bandwidth Product 1.5MHz
Power Supply Rejection Ratio (PSRR) 80dB
Gain 15 dB
Max Output Power 1W
Max Output Power x Channels @ Load 1W x 2 @ 8 Ω
Harmonic Distortion 1%
Dimensions
Height Seated (Max) 1mm
Length 4mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Alternative Model
