TS482IST
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Audio
Description
EAR99 TS482 Tape & Reel (TR) Depop audio amplifier 2V 3mm 107mW x 2 @ 16Ohm 500nA
PDF
/
Buying Options
Total Price: USD $1
Unit Price: USD $1.0032
≥1 USD $1.0032
≥10 USD $0.89496
≥100 USD $0.849728
≥500 USD $0.697928
≥1000 USD $0.652397
≥3000 USD $0.576523
Inventory: 2395
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Number of Pins 8
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
JESD-609 Code e4
Feature Depop
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Type Class AB
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Audio/Video Amplifiers
Max Power Dissipation 580mW
Voltage - Supply 2V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Terminal Pitch 0.65mm
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number TS482
Pin Count 8
Output Type Headphones, 2-Channel (Stereo)
Operating Supply Voltage 5V
Supply Voltage-Min (Vsup) 2V
Number of Channels 2
Nominal Supply Current 5.5mA
Power Dissipation 580mW
Quiescent Current 5.5mA
Output Power 107mW
Supply Type Single
Input Offset Voltage (Vos) 5mV
Bandwidth 20 kHz
Gain Bandwidth Product 2.2MHz
Power Supply Rejection Ratio (PSRR) 85dB
Max Output Power 107mW
Input Bias Current 500nA
Max Output Power x Channels @ Load 107mW x 2 @ 16 Ω
Dimensions
Height Seated (Max) 1.1mm
Length 3mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
