TDA7575BPDTR
RoHS
RoHS compliant
RoHS compliantPackage PowerSO-36 Exposed Bottom Pad
Category Integrated Circuits (ICs) / Linear - Amplifiers - Audio
Description
8542.33.00.01 TDA7575 Tape & Reel (TR) Differential Inputs I2C Mute Short-Circuit and Thermal Protection Standby audio amplifier 8V 15.9mm 150W x 1 @ 1Ohm; 75W x 2 @ 2Ohm 200mA
PDF
/
Buying Options
Total Price: USD $3.32
Unit Price: USD $3.31835
≥1 USD $3.31835
≥10 USD $2.7227
≥100 USD $2.63815
≥500 USD $2.55265
≥1000 USD $2.46715
Inventory: 2476
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 11mm
Length 15.9mm
Height Seated (Max) 3.43mm
Technical
Harmonic Distortion 10%
Max Output Power x Channels @ Load 150W x 1 @ 1 Ω; 75W x 2 @ 2 Ω
Max Output Power 150W
Gain 26 dB
Voltage Gain 26dB
Bandwidth 22 kHz
Input Offset Voltage (Vos) 45mV
Supply Type Single
Common Mode Rejection Ratio 56 dB
Output Power 150W
Supply Current-Max 200mA
Power Dissipation 86W
Number of Channels 2
Supply Voltage-Min (Vsup) 8V
Power Supplies 14.4V
Supply Voltage-Max (Vsup) 18V
Operating Supply Voltage 15V
Output Type 1-Channel (Mono) or 2-Channel (Stereo)
Pin Count 36
Base Part Number TDA7575
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 0.65mm
Number of Functions 1
Peak Reflow Temperature (Cel) 245
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 8V~18V
Technology BCDMOS
Max Power Dissipation 86W
Subcategory Audio/Video Amplifiers
HTS Code 8542.33.00.01
Terminal Finish Matte Tin (Sn) - annealed
Type Class AB
ECCN Code EAR99
Number of Terminations 36
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Feature Differential Inputs, I2C, Mute, Short-Circuit and Thermal Protection, Standby
JESD-609 Code e3
Packaging Tape & Reel (TR)
Operating Temperature -55°C~150°C TJ
Physical
Number of Pins 36
Package / Case PowerSO-36 Exposed Bottom Pad
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 18 Weeks
