TDA7495
RoHS
RoHS compliant
RoHS compliantPackage Multiwatt-15 (Vertical, Bent and Staggered Leads)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Audio
Description
8542.39.00.01 TDA7495 Tube Depop Mute Short-Circuit and Thermal Protection Standby Volume Control audio amplifier 11V 1.27mm 11W x 2 @ 8Ohm 100mA
PDF
/
Buying Options
Total Price: USD $1.43
Unit Price: USD $1.4269
≥1 USD $1.4269
≥10 USD $1.1704
≥100 USD $1.1343
≥500 USD $1.09725
≥1000 USD $1.06115
Inventory: 1600
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Multiwatt-15 (Vertical, Bent and Staggered Leads)
Number of Pins 15
Technical
Operating Temperature -20°C~85°C TA
Packaging Tube
JESD-609 Code e0
Feature Depop, Mute, Short-Circuit and Thermal Protection, Standby, Volume Control
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 15
ECCN Code EAR99
Type Class AB
HTS Code 8542.39.00.01
Subcategory Audio/Video Amplifiers
Max Power Dissipation 20W
Technology BIPOLAR
Voltage - Supply 11V~35V
Terminal Position ZIG-ZAG
Terminal Pitch 1.27mm
Base Part Number TDA7495
Output Type 2-Channel (Stereo)
Operating Supply Voltage 28V
Supply Voltage-Max (Vsup) 35V
Supply Voltage-Min (Vsup) 11V
Number of Channels 2
Power Dissipation 20W
Supply Current-Max 100mA
Output Power 11W
Supply Type Single
Nominal Input Voltage 8V
Voltage Gain 30dB
Power Supply Rejection Ratio (PSRR) 65dB
Gain 30 dB
Max Output Power 11W
Max Output Power x Channels @ Load 11W x 2 @ 8 Ω
Harmonic Distortion 10%
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
