TDA7492P13TR
RoHS
RoHS compliant
RoHS compliantPackage 36-PowerFSOP (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Audio
Description
8542.33.00.01 TDA7492 Tape & Reel (TR) Differential Inputs Mute Short-Circuit and Thermal Protection Standby audio amplifier 8V 10.3mm 25W x 2 @ 8Ohm 26mA
PDF
/
Buying Options
Total Price: USD $3.25
Unit Price: USD $3.2472
≥1 USD $3.2472
≥10 USD $2.91984
≥100 USD $2.760384
≥500 USD $2.39228
≥1000 USD $2.26959
≥3000 USD $2.036514
Inventory: 3978
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 36-PowerFSOP (0.295, 7.50mm Width)
Number of Pins 36
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
JESD-609 Code e3
Feature Differential Inputs, Mute, Short-Circuit and Thermal Protection, Standby
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 36
ECCN Code EAR99
Type Class D
HTS Code 8542.33.00.01
Subcategory Audio/Video Amplifiers
Max Power Dissipation 5W
Voltage - Supply 8V~26V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Terminal Pitch 0.5mm
Base Part Number TDA7492
Pin Count 36
Output Type 2-Channel (Stereo)
Supply Voltage-Max (Vsup) 26V
Power Supplies 20V
Supply Voltage-Min (Vsup) 8V
Number of Channels 2
Nominal Supply Current 26mA
Output Power 25W
Supply Type Single
Bandwidth 22 kHz
Voltage Gain 33.6dB
Max Output Power 25W
Max Output Power x Channels @ Load 25W x 2 @ 8 Ω
Harmonic Distortion 10%
Dimensions
Height Seated (Max) 2.45mm
Length 10.3mm
Width 7.5mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
