TDA7492P image
Favorite
TDA7492P image
Favorite
RoHS
RoHS RoHS compliant
Package 36-PowerFSOP (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Audio
Description EAR99 TDA7492 Tube Differential Inputs Mute Short-Circuit and Thermal Protection Standby audio amplifier 8V 10.3mm 25W x 2 @ 8Ohm 35mA
PDF
/
Buying Options
Total Price: USD $1.96
Unit Price: USD $1.95985
≥1 USD $1.95985
≥10 USD $1.60835
≥100 USD $1.558
≥500 USD $1.50765
≥1000 USD $1.45825
Inventory: 53801
Minimum: 1
-
+

Technical Details

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 7 months ago)

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case 36-PowerFSOP (0.295, 7.50mm Width)
Number of Pins 36

Technical

Operating Temperature -40°C~85°C TA
Packaging Tube
JESD-609 Code e3
Feature Differential Inputs, Mute, Short-Circuit and Thermal Protection, Standby
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 36
ECCN Code EAR99
Type Class D
Terminal Finish Matte Tin (Sn) - annealed
Subcategory Audio/Video Amplifiers
Voltage - Supply 8V~26V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Terminal Pitch 0.5mm
Base Part Number TDA7492
Pin Count 36
Output Type 2-Channel (Stereo)
Supply Voltage-Min (Vsup) 8V
Number of Channels 2
Supply Current-Max 35mA
Output Power 25W
Bandwidth 22 kHz
Voltage Gain 33.6dB
Max Output Power 25W
Max Output Power x Channels @ Load 25W x 2 @ 8 Ω
Harmonic Distortion 10%
Load Impedance 8Ohm

Dimensions

Length 10.3mm
Width 7.5mm

Compliance

Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
