TDA7491HV13TR
RoHS
RoHS compliant
RoHS compliantPackage 36-PowerFSOP (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Audio
Description
EAR99 TDA7491 Tape & Reel (TR) Depop Differential Inputs Mute Short-Circuit and Thermal Protection Standby audio amplifier 5V 2.4mm 20W x 2 @ 8Ohm 35mA
PDF
/
Buying Options
Total Price: USD $3.34
Unit Price: USD $3.3352
≥1 USD $3.3352
≥10 USD $2.992
≥100 USD $2.829024
≥500 USD $2.451768
≥1000 USD $2.326016
≥3000 USD $2.087114
Inventory: 1038
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 6 months ago)
Physical
Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 36-PowerFSOP (0.295, 7.50mm Width)
Number of Pins 36
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
JESD-609 Code e3
Feature Depop, Differential Inputs, Mute, Short-Circuit and Thermal Protection, Standby
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 36
ECCN Code EAR99
Type Class D
Subcategory Audio/Video Amplifiers
Technology BIPOLAR
Voltage - Supply 5V~18V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 225
Number of Functions 1
Base Part Number TDA7491
Pin Count 36
Output Type 2-Channel (Stereo)
Supply Voltage-Max (Vsup) 18V
Power Supplies 18V
Supply Voltage-Min (Vsup) 5V
Number of Channels 2
Supply Current-Max 35mA
Output Power 20W
Bandwidth 22 kHz
Voltage Gain 32dB
Max Output Power 20W
Max Output Power x Channels @ Load 20W x 2 @ 8 Ω
Harmonic Distortion 10%
Load Impedance 8Ohm
Dimensions
Height 2.4mm
Length 10.5mm
Width 7.6mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
