TDA7265
RoHS
RoHS compliant
RoHS compliantPackage Multiwatt-11 (Vertical, Bent and Staggered Leads)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Audio
Description
EAR99 TDA7265 Tube Depop Mute Short-Circuit and Thermal Protection Standby audio amplifier 24V 10.7mm 25W x 2 @ 8Ohm 500nA
PDF
/
Buying Options
Total Price: USD $5.55
Unit Price: USD $5.5528
≥1 USD $5.5528
≥10 USD $5.0204
≥100 USD $4.786496
≥500 USD $4.156064
≥1000 USD $3.969293
≥3000 USD $3.619053
Inventory: 616
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Contact Plating Lead, Tin
Mount Through Hole
Mounting Type Through Hole
Package / Case Multiwatt-11 (Vertical, Bent and Staggered Leads)
Number of Pins 11
Weight 8.164663g
Technical
Operating Temperature -20°C~85°C TA
Packaging Tube
JESD-609 Code e3
Feature Depop, Mute, Short-Circuit and Thermal Protection, Standby
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 11
ECCN Code EAR99
Type Class AB
Terminal Finish Tin (Sn)
Subcategory Audio/Video Amplifiers
Max Power Dissipation 30W
Technology BIPOLAR
Voltage - Supply ±5V~25V
Terminal Position ZIG-ZAG
Number of Functions 1
Terminal Pitch 1.7mm
Base Part Number TDA7265
Pin Count 11
Output Type 2-Channel (Stereo)
Number of Channels 2
Nominal Supply Current 4.5A
Power Dissipation 30W
Quiescent Current 80mA
Output Power 25W
Supply Type Dual
Input Offset Voltage (Vos) 20mV
Bandwidth 22 kHz
Voltage Gain 80dB
Power Supply Rejection Ratio (PSRR) 60dB
Gain 80 dB
Max Dual Supply Voltage 25V
Max Output Power 25W
Min Dual Supply Voltage 5V
Dual Supply Voltage 24V
Input Bias Current 500nA
Max Output Power x Channels @ Load 25W x 2 @ 8 Ω
Harmonic Distortion 10%
Load Impedance 4 Ω
Dimensions
Height 10.7mm
Length 19.6mm
Width 5mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
