TDA7253
RoHS
RoHS compliant
RoHS compliantPackage Clipwatt-11 (Vertical, Bent and Staggered Leads)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Audio
Description
8542.33.00.01 TDA7253 Tube Mute Short-Circuit and Thermal Protection audio amplifier 10V 1.7mm 10W x 1 @ 8Ohm 2.5A
PDF
/
Buying Options
Total Price: USD $0.81
Unit Price: USD $0.8056
≥1 USD $0.8056
≥10 USD $0.6612
≥100 USD $0.6403
≥500 USD $0.62035
≥1000 USD $0.59945
Inventory: 1000
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Clipwatt-11 (Vertical, Bent and Staggered Leads)
Number of Pins 11
Technical
Operating Temperature 0°C~70°C TA
Packaging Tube
JESD-609 Code e3
Feature Mute, Short-Circuit and Thermal Protection
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 11
ECCN Code EAR99
Type Class AB
Terminal Finish Matte Tin (Sn)
HTS Code 8542.33.00.01
Subcategory Audio/Video Amplifiers
Max Power Dissipation 25W
Technology BIPOLAR
Voltage - Supply 10V~32V
Terminal Position ZIG-ZAG
Peak Reflow Temperature (Cel) 250
Number of Functions 1
Terminal Pitch 1.7mm
Base Part Number TDA7253
Pin Count 11
Output Type 1-Channel (Mono)
Operating Supply Voltage 28V
Supply Voltage-Max (Vsup) 32V
Supply Voltage-Min (Vsup) 10V
Number of Channels 1
Nominal Supply Current 2.5A
Power Dissipation 25W
Output Power 10W
Supply Type Single
Bandwidth 80 kHz
Power Supply Rejection Ratio (PSRR) 60dB
Gain 30 dB
Max Output Power 10W
Max Output Power x Channels @ Load 10W x 1 @ 8 Ω
Harmonic Distortion 10%
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Alternative Model
