TDA2004R
RoHS
RoHS compliant
RoHS compliantPackage Multiwatt-11 (Vertical, Bent and Staggered Leads)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Audio
Description
EAR99 TDA2004 Tube Short-Circuit and Thermal Protection audio amplifier 8V 1.7mm 12W x 2 @ 2Ohm 12W
PDF
/
Buying Options
Total Price: USD $2.43
Unit Price: USD $2.431851
≥1 USD $2.431851
≥10 USD $2.162372
≥100 USD $1.993621
≥500 USD $1.7556
≥1000 USD $1.69765
≥5000 USD $1.65
Inventory: 10628
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Harmonic Distortion 10%
Max Output Power x Channels @ Load 12W x 2 @ 2 Ω
Max Output Power 12W
Gain 50 dB
Voltage Gain 90dB
Bandwidth 22 kHz
Supply Type Single
Output Power 12W
Power Dissipation 30W
Number of Channels 2
Supply Voltage-Min (Vsup) 8V
Power Supplies 8/18V
Supply Voltage-Max (Vsup) 18V
Operating Supply Voltage 15V
Output Type 2-Channel (Stereo)
Pin Count 25
Base Part Number TDA2004
Terminal Pitch 1.7mm
Number of Functions 1
Peak Reflow Temperature (Cel) 225
Terminal Position ZIG-ZAG
Voltage - Supply 8V~18V
Technology BIPOLAR
Max Power Dissipation 30W
Subcategory Audio/Video Amplifiers
Terminal Finish MATTE TIN
Type Class B
ECCN Code EAR99
Number of Terminations 25
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Short-Circuit and Thermal Protection
JESD-609 Code e3
Packaging Tube
Operating Temperature -40°C~150°C TJ
Physical
Number of Pins 11
Package / Case Multiwatt-11 (Vertical, Bent and Staggered Leads)
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 8 months ago)
Factory Lead Time 12 Weeks
