RoHS
/
Package SOT-93
Category Integrated Circuits (ICs) / Linear - Amplifiers - Audio
Description SWITCHING RoHS Compliant Through Hole NPN audio amplifier 150C 50W 10A 14.9mm
PDF
/
Inventory: 916
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant
Radiation Hardening No

Dimensions

Width 5.65mm
Length 16.2mm
Height 14.9mm

Technical

Continuous Collector Current 10A
DC Current Gain-Min (hFE) 5
hFE Min 10
Emitter Base Voltage (VEBO) 7V
Collector Emitter Saturation Voltage 5V
Max Collector Current 10A
Collector Emitter Voltage (VCEO) 600V
Transistor Application SWITCHING
Case Connection ISOLATED
Power Dissipation 50W
Element Configuration Single
Polarity NPN
Number of Elements 1
JESD-30 Code R-PSFM-T3
Pin Count 3
Subcategory Other Transistors
Min Operating Temperature -65°C
Max Operating Temperature 150°C
ECCN Code EAR99
Number of Terminations 3
Published 2012

Physical

Number of Pins 218
Package / Case SOT-93
Mount Through Hole
