BA7760
RoHS
/
Package DIP
Category Integrated Circuits (ICs) / Linear - Amplifiers - Audio
Description
RoHS Compliant Lead Free Through Hole AUDIO AMPLIFIER audio amplifier 75C 0.7dB 6.09mA 19.4mm
PDF
/
Buying Options
Total Price: USD $3.86
Unit Price: USD $3.8646
≥1 USD $3.8646
≥10 USD $3.1711
≥100 USD $3.0723
≥500 USD $2.97255
≥1000 USD $2.87375
Inventory: 20691
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Width 7.62mm
Length 19.4mm
Height Seated (Max) 4.55mm
Technical
Harmonic Distortion 0.008%
Consumer IC Type AUDIO AMPLIFIER
Gain 0.7 dB
Supply Current-Max 6.09mA
Quiescent Current 4.87mA
Number of Channels 2
Supply Voltage-Min (Vsup) 6V
Temperature Grade COMMERCIAL EXTENDED
Power Supplies 12V
Operating Temperature (Min) -25°C
Operating Temperature (Max) 75°C
Qualification Status Not Qualified
Pin Count 14
Time@Peak Reflow Temperature-Max (s) 10
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Technology BIPOLAR
Subcategory Audio/Video Amplifiers
HTS Code 8542.33.00.01
Terminal Finish TIN/TIN COPPER
ECCN Code EAR99
Number of Terminations 14
Pbfree Code yes
JESD-609 Code e3/e2
Physical
Number of Pins 14
Package / Case DIP
Mount Through Hole
