BA3576FS-E2
RoHS
/
Package SOP
Category Integrated Circuits (ICs) / Linear - Amplifiers - Audio
Description
GULL WING RoHS Compliant Lead Free Surface Mount audio amplifier 60C 11.5dB 0.0256W 4.5mA
PDF
/
Inventory: 6349
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Width 5.4mm
Length 8.7mm
Height Seated (Max) 1.9mm
Technical
Harmonic Distortion 10%
Consumer IC Type AUDIO PREAMPLIFIER
Max Output Power 25.6mW
Gain 11.5 dB
Output Power 0.0256W
Supply Current-Max 8mA
Quiescent Current 4.5mA
Number of Channels 2
Supply Voltage-Min (Vsup) 2.6V
Temperature Grade COMMERCIAL
Power Supplies 3V
Supply Voltage-Max (Vsup) 3.6V
Operating Temperature (Min) -15°C
Operating Temperature (Max) 60°C
Qualification Status Not Qualified
JESD-30 Code R-PDSO-G20
Pin Count 20
Time@Peak Reflow Temperature-Max (s) 10
Terminal Pitch 0.8mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BIPOLAR
Subcategory Audio/Video Amplifiers
HTS Code 8542.33.00.01
Terminal Finish TIN/TIN COPPER
ECCN Code EAR99
Number of Terminations 20
Pbfree Code yes
JESD-609 Code e3/e2
Packaging Tape & Reel (TR)
Physical
Package / Case SOP
Mount Surface Mount
