NCP2890DMR2
RoHS
/
Package 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Audio
Description
GULL WING Non-RoHS Compliant Contains Lead Surface Mount Amplifier IC Class AB -40C~85C TA 20kHz 1.08W 1.7mA
PDF
/
Buying Options
Total Price: USD $6.91
Unit Price: USD $6.91315
≥1 USD $6.91315
≥10 USD $5.67245
≥100 USD $5.4948
≥500 USD $5.31715
≥1000 USD $5.14045
Inventory: 12299
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Surface Mount YES
Number of Pins 8
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Published 2004
JESD-609 Code e0
Feature Depop, Differential Inputs, Short-Circuit and Thermal Protection, Shutdown
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Type Class AB
Terminal Finish Tin/Lead (Sn/Pb)
Subcategory Audio/Video Amplifiers
Max Power Dissipation 650mW
Voltage - Supply 2.2V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 240
Number of Functions 1
Terminal Pitch 0.65mm
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number NCP2890
Pin Count 8
Qualification Status Not Qualified
Output Type 1-Channel (Mono)
Operating Supply Voltage 5V
Supply Voltage-Min (Vsup) 2.2V
Number of Channels 1
Nominal Supply Current 1.7mA
Quiescent Current 1.9mA
Output Power 1.08W
Supply Type Single
Bandwidth 20 kHz
Max Output Power 1.08W
Max Output Power x Channels @ Load 1.08W x 1 @ 8 Ω
Dimensions
Height Seated (Max) 1.1mm
Length 3mm
Width 3mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
