LV47011P-E
RoHS
/
Package 25-SSIP Exposed Pad, Formed Leads
Category Integrated Circuits (ICs) / Linear - Amplifiers - Audio
Description
RoHS Compliant Lead Free Through Hole Obsolete Amplifier IC Class AB -40C~85C TA 26dB 50W 29W x 4 @ 4Ohm
PDF
/
Buying Options
Total Price: USD $4.95
Unit Price: USD $4.954384
≥1 USD $4.954384
≥10 USD $4.673949
≥100 USD $4.409389
≥500 USD $4.159797
≥1000 USD $3.924341
Inventory: 1174
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Technical
Max Output Power x Channels @ Load 29W x 4 @ 4 Ω
Max Output Power 29W
Voltage Gain 26dB
Output Power 50W
Power Dissipation 50W
Number of Channels 4
Operating Supply Voltage 14.4V
Output Type 4-Channel (Quad)
Pin Count 25
Base Part Number LV47011
Voltage - Supply 8V~16V
Max Power Dissipation 50W
Type Class AB
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Feature Mute, Short-Circuit and Thermal Protection
Published 2011
Packaging Tape & Box (TB)
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 25
Package / Case 25-SSIP Exposed Pad, Formed Leads
Mounting Type Through Hole
Supply Chain
Lifecycle Status LAST SHIPMENTS (Last Updated: 1 day ago)
