LA4425PV-TLM-H
RoHS
/
Package 44-LSSOP (0.220, 5.60mm Width) Exposed Pad
Category Integrated Circuits (ICs) / Linear - Amplifiers - Audio
Description
e6 LA4425 Tape & Reel (TR) Depop Overvoltage Short Circuit Thermal Protection audio amplifier 13.2V 0.635mm 6W x 1 @ 4Ohm 65mA
PDF
/
Buying Options
Total Price: USD $3.87
Unit Price: USD $3.87125
≥1 USD $3.87125
≥10 USD $3.1768
≥100 USD $3.07705
≥500 USD $2.97825
≥1000 USD $2.8785
Inventory: 1153
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Lifecycle Status LAST SHIPMENTS (Last Updated: 2 weeks ago)
Physical
Mounting Type Surface Mount
Package / Case 44-LSSOP (0.220, 5.60mm Width) Exposed Pad
Surface Mount YES
Number of Pins 44
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Published 2008
JESD-609 Code e6
Feature Depop, Overvoltage, Short Circuit, Thermal Protection
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 44
Type Class AB
Terminal Finish Tin/Bismuth (Sn/Bi)
Subcategory Audio/Video Amplifiers
Max Power Dissipation 5.15W
Voltage - Supply 5V~16V
Terminal Position DUAL
Terminal Form GULL WING
Number of Functions 1
Terminal Pitch 0.635mm
Base Part Number LA4425
Pin Count 44
Output Type 1-Channel (Mono)
Operating Supply Voltage 13.2V
Number of Channels 1
Nominal Supply Current 65mA
Power Dissipation 5.15W
Output Power 5W
Halogen Free Halogen Free
Voltage Gain 45dB
Max Output Power 6W
Max Output Power x Channels @ Load 6W x 1 @ 4 Ω
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
