RoHS
/
Package TO-92
Category Integrated Circuits (ICs) / Linear - Amplifiers - Audio
Description AMPLIFIER WIRE RoHS Compliant Through Hole audio amplifier 150C 120MHz 0.75W 1A
PDF
/
Inventory: 4493
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mount Through Hole
Package / Case TO-92
Number of Pins 3
Weight 72.574779g

Technical

Number of Terminations 3
ECCN Code EAR99
Max Operating Temperature 150°C
Min Operating Temperature -55°C
HTS Code 8541.29.00.75
Subcategory Other Transistors
Terminal Position BOTTOM
Terminal Form WIRE
Pin Count 3
Qualification Status Not Qualified
Number of Elements 1
Polarity PNP
Configuration SINGLE
Transistor Application AMPLIFIER
Collector Emitter Voltage (VCEO) 80V
Max Collector Current 1A
Transition Frequency 120MHz
Collector Base Voltage (VCBO) 80V
Power Dissipation-Max (Abs) 0.75W
Emitter Base Voltage (VEBO) 5V
DC Current Gain-Min (hFE) 50

Dimensions

Height 12.7mm
Length 152.4mm
Width 76.2mm

Compliance

RoHS Status RoHS Compliant
