NTE1294
RoHS
/
Package DIP
Category Integrated Circuits (ICs) / Linear - Amplifiers - Audio
Description
RoHS Compliant Through Hole AUDIO AMPLIFIER Not Qualified audio amplifier 150C 20kHz 45dB 2W
PDF
/
Buying Options
Total Price: USD $62.65
Unit Price: USD $62.645971
≥1 USD $62.645971
≥10 USD $59.09997
≥100 USD $55.754689
≥500 USD $52.598768
≥1000 USD $49.621474
Inventory: 3860
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 76.2mm
Length 152.4mm
Height 12.7mm
Technical
Harmonic Distortion 10%
Consumer IC Type AUDIO AMPLIFIER
Power - Output 1.2W
Gain 45 dB
Bandwidth 20 kHz
Current - Input Bias 100nA
Output Power 2W
Supply Current-Max 12mA
Current - Output 1.5A
Min Supply Voltage 3V
Max Supply Voltage 16V
Number of Channels 1
Qualification Status Not Qualified
Pin Count 8
Terminal Pitch 2.54mm
Number of Functions 1
Terminal Position DUAL
Subcategory Audio/Video Amplifiers
Min Operating Temperature -40°C
Max Operating Temperature 150°C
ECCN Code EAR99
Number of Terminations 8
Physical
Weight 7.257478g
Number of Pins 8
Package / Case DIP
Mount Through Hole
