MAX9761ETI+
RoHS
RoHS compliant
RoHS compliantPackage 28-WFQFN Exposed Pad
Category Integrated Circuits (ICs) / Linear - Amplifiers - Audio
Description
NO LEAD ROHS3Compliant Lead Free Surface Mount Amplifier IC Class AB -40C~85C TA 22kHz 3W 13mA
PDF
/
Buying Options
Total Price: USD $3.49
Unit Price: USD $3.488976
≥1 USD $3.488976
≥10 USD $3.291481
≥100 USD $3.105177
≥500 USD $2.929406
≥1000 USD $2.76359
Inventory: 1137
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 5mm
Length 5mm
Height Seated (Max) 0.8mm
Technical
Max Output Power x Channels @ Load 3W x 2 @ 3 Ω; 200mW x 2 @ 16 Ω
Max Output Power 3W
Bandwidth 22 kHz
Supply Type Single
Output Power 3W
Quiescent Current 13mA
Number of Channels 2
Operating Supply Voltage 5V
Output Type 2-Channel (Stereo) with Stereo Headphones
Qualification Status Not Qualified
JESD-30 Code S-XQCC-N28
Pin Count 28
Base Part Number MAX9761
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.5mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form NO LEAD
Terminal Position QUAD
Voltage - Supply 4.5V~5.5V
Technology BICMOS
Max Power Dissipation 1.667W
HTS Code 8542.33.00.01
Terminal Finish Matte Tin (Sn)
Type Class AB
ECCN Code EAR99
Number of Terminations 28
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Depop, Input Multiplexer, Mute, Shutdown, Thermal Protection
JESD-609 Code e3
Published 2003
Packaging Tube
Operating Temperature -40°C~85°C TA
Physical
Package / Case 28-WFQFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
