MAX9724DEBC+T
RoHS
RoHS compliant
RoHS compliantPackage 12-WFBGA, WLCSP
Category Integrated Circuits (ICs) / Linear - Amplifiers - Audio
Description
BALL ROHS3Compliant Surface Mount Obsolete Amplifier IC Class AB -40C~85C TA 22kHz 0.045W 5.5mA
PDF
/
Buying Options
Total Price: USD $0.92
Unit Price: USD $0.91876
≥1 USD $0.91876
≥10 USD $0.866753
≥100 USD $0.817688
≥500 USD $0.771405
≥1000 USD $0.72774
Inventory: 1086
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 12-WFBGA, WLCSP
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Published 2008
Series DirectDrive?
Feature Depop, Short-Circuit and Thermal Protection, Shutdown
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 12
ECCN Code EAR99
Type Class AB
HTS Code 8542.33.00.01
Subcategory Audio/Video Amplifiers
Technology BICMOS
Voltage - Supply 2.5V~5.5V
Terminal Position BOTTOM
Terminal Form BALL
Number of Functions 1
Terminal Pitch 0.5mm
Base Part Number MAX9724
Pin Count 12
JESD-30 Code R-PBGA-B12
Qualification Status Not Qualified
Output Type Headphones, 2-Channel (Stereo)
Supply Voltage-Max (Vsup) 5.5V
Power Supplies 5V
Supply Voltage-Min (Vsup) 2.5V
Number of Channels 2
Supply Current-Max 5.5mA
Output Power 0.045W
Bandwidth 22 kHz
Max Output Power 45mW
Max Output Power x Channels @ Load 45mW x 2 @ 32 Ω
Dimensions
Height Seated (Max) 0.67mm
Length 2.02mm
Width 1.54mm
Compliance
RoHS Status ROHS3 Compliant
