MAX9723AEBE+T
RoHS
RoHS compliant
RoHS compliantPackage 16-WFBGA, CSPBGA
Category Integrated Circuits (ICs) / Linear - Amplifiers - Audio
Description
BALL ROHS3Compliant Lead Free Surface Mount Amplifier IC Class AB -40C~85C TA 90dB 60mW 4mA
PDF
/
Buying Options
Total Price: USD $1.44
Unit Price: USD $1.444667
≥1 USD $1.444667
≥10 USD $1.362889
≥100 USD $1.285747
≥500 USD $1.212971
≥1000 USD $1.144313
Inventory: 1098
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 16-WFBGA, CSPBGA
Number of Pins 16
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Published 2012
Series DirectDrive?
JESD-609 Code e1
Feature Bass Boost, Depop, I2C, Mute, Short-Circuit and Thermal Protection, Shutdown, Volume Control
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
ECCN Code EAR99
Type Class AB
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
HTS Code 8542.33.00.01
Max Power Dissipation 1.349W
Technology BICMOS
Voltage - Supply 1.8V~3.6V
Terminal Position BOTTOM
Terminal Form BALL
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Base Part Number MAX9723
Pin Count 16
Output Type Headphones, 2-Channel (Stereo)
Number of Channels 1
Nominal Supply Current 4mA
Quiescent Current 4mA
Output Power 60mW
Voltage Gain 0dB
Power Supply Rejection Ratio (PSRR) 90dB
Max Output Power 60mW
Max Output Power x Channels @ Load 60mW x 2 @ 16 Ω
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
