ISL6522CBZ
RoHS
/
Package /
Category Integrated Circuits (ICs) / Linear - Amplifiers - Audio
Description
GULL WING Non-RoHS Compliant SWITCHING CONTROLLER PUSH-PULL Amplifier IC (Type) 70C 1000kHz 0.3A 8.65mm
PDF
/
Buying Options
Total Price: USD $2.67
Unit Price: USD $2.6664
≥1 USD $2.6664
Inventory: 1133
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 3.9mm
Length 8.65mm
Height Seated (Max) 1.75mm
Technical
Switching Frequency-Max 1000kHz
Switcher Configuration PUSH-PULL
Control Technique PULSE WIDTH MODULATION
Input Voltage (Max) 13.2V
Output Current-Max 0.3A
Control Mode VOLTAGE-MODE
Input Voltage (Min) 10.8V
Analog IC - Other Type SWITCHING CONTROLLER
Temperature Grade COMMERCIAL
Input Voltage-Nom 12V
Operating Temperature (Max) 70°C
Qualification Status Not Qualified
JESD-30 Code R-PDSO-G14
Pin Count 16, 14, 14
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 1.27mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Subcategory Switching Regulator or Controllers
HTS Code 8542.39.00.01
Terminal Finish Matte Tin (Sn) - annealed
ECCN Code EAR99
Number of Terminations 14
Moisture Sensitivity Level (MSL) 3
JESD-609 Code e3
Physical
Surface Mount YES
