PLED5Q12
RoHS
RoHS compliant
RoHS compliantPackage 2-VDFN
Category Circuit Protection / Lighting Protection
Description
LED PROTECTOR 5V BI-DIR 2X2 QFN
PDF
/
Inventory: 3540
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Height Seated (Max) 0.9mm
Technical
Voltage - Clamping 5.2V
Multiplexed Display Capability NO
Number of Segments 1
Hold Current 5mA
Interface IC Type LED DISPLAY DRIVER
RMS Current (Irms) 500mA
Breakdown Voltage 4.6V
Direction Unidirectional
Number of Circuits 1
Temperature Grade INDUSTRIAL
Working Voltage 3.5V
Operating Supply Voltage 40V
Pin Count 2
Time@Peak Reflow Temperature-Max (s) 30
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form BUTT
Terminal Position BOTTOM
Technology LED Shunt
Applications LED Protection
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
JESD-609 Code e3
Series PLED?
Published 2010
Packaging Tape & Reel (TR)
Physical
Number of Pins 2
Surface Mount YES
Package / Case 2-VDFN
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
