WP934SA/3YD
RoHS
RoHS compliant
RoHS compliantPackage /
Category Optoelectronics / LEDs - Circuit Board Indicators, Arrays, Light Bars, Bar Graphs
Description
LED IND 3MM TRI-LVL RA YLW DIFF
PDF
/
Buying Options
Total Price: USD $1.23
Unit Price: USD $1.232
≥1 USD $1.232
≥10 USD $0.77792
≥100 USD $0.57552
≥500 USD $0.528845
≥1000 USD $0.435512
≥3000 USD $0.413741
Inventory: 515
Minimum: 1
-
+
Technical Details
Technical
Forward Voltage 2.1V
Luminous Intensity 11.5 mcd
Lens Type Diffused, Tinted
Wavelength - Peak 590nm
Lens Color Yellow
Overall Height 15.24mm
T-code T-1
Size 2.9mm
Lens Style Diffused, Round, Tinted
Forward Current 20mA
Optoelectronic Device Type SINGLE COLOR LED ARRAY
Viewing Angle 40°
Configuration 3 High
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Terminal Pitch 2.54mm
Number of Functions 3
Packing Method BULK
HTS Code 8541.40.20.00
Additional Feature UL RECOGNIZED, IC COMPATIBLE, HIGH RELIABILITY
Voltage - Rated 2.1V
Color Yellow (x 3)
ECCN Code EAR99
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Published 2007
Packaging Tube
Compliance
RoHS Status ROHS3 Compliant
Physical
Mounting Type Through Hole, Right Angle
Mount Through Hole
Supply Chain
Factory Lead Time 12 Weeks
