5952201002F
RoHS
RoHS compliant
RoHS compliantPackage /
Category Optoelectronics / LEDs - Circuit Board Indicators, Arrays, Light Bars, Bar Graphs
Description
LED PRISM 2MM SQ HI INT GRN SMD
PDF
/
Inventory: 4648
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Overall Height 3.45mm
Forward Voltage-Max 2.6V
Wavelength - Peak 560nm
Millicandela Rating 11mcd
Luminous Intensity 8.5 mcd
Lens Size 5.00mm Dia
Lens Style Round with Domed Top
Viewing Angle 40 deg
Current 20mA
Configuration Single
Operating Temperature (Min) -30°C
Operating Temperature (Max) 85°C
Terminal Pitch 2.94mm
Number of Functions 1
Packing Method STRIP
Subcategory Visible LEDs
HTS Code 8541.40.20.00
Additional Feature SUPPORTS INFRARED
Voltage - Rated 2.1V
Color Green
Terminal Finish Copper/Nickel/Gold (Cu/Ni/Au)
Number of Terminations 2
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e4
Series 595
Published 2002
Packaging Bulk
Physical
Shape RECTANGULAR
Surface Mount YES
Mounting Type Surface Mount, Right Angle
