5922828013F
RoHS
/
Package /
Category Optoelectronics / LEDs - Circuit Board Indicators, Arrays, Light Bars, Bar Graphs
Description
LED Bi-Level Uni-Color White 4-Pin T/R
PDF
/
Inventory: 2794
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount, Through Hole
Mounting Type Surface Mount, Right Angle
Number of Pins 4
Technical
Packaging Tape & Reel (TR)
Published 2008
Series 592
JESD-609 Code e2
Part Status Obsolete
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 4
Terminal Finish Tin/Silver/Nickel (Sn/Ag/Ni)
Max Operating Temperature 100°C
Min Operating Temperature -40°C
Color White (x 2)
Packing Method TAPE AND REEL 13"
Number of Functions 2
Depth 4.32mm
Number of Elements 2
Configuration 2 High
Power Dissipation 85mW
Viewing Angle 40 °
Optoelectronic Device Type SINGLE COLOR LED ARRAY
Forward Current 20mA
Lens Style Round with Domed Top
Lens Size 5.00mm Dia
Test Current 10mA
Forward Voltage 3.5V
Luminous Intensity 19 mcd
Illumination Color White
Lens Color Clear
T-code T-1
Dimensions
Height 10.922mm
Length 16.89mm
Width 4.318mm
Compliance
RoHS Status RoHS Compliant
