5690103333
RoHS
/
Package /
Category Optoelectronics / LEDs - Circuit Board Indicators, Arrays, Light Bars, Bar Graphs
Description
LED 2X2 3MM HI DENSITY YEL PCMNT
PDF
/
Buying Options
Total Price: USD $1.69
Unit Price: USD $1.688238
≥1 USD $1.688238
≥10 USD $1.592684
≥100 USD $1.50253
≥500 USD $1.417481
≥1000 USD $1.337242
Inventory: 1072
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole, Right Angle
Number of Pins 8
Technical
Packaging Bulk
Published 2002
Series 569
JESD-609 Code e4
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
Terminal Finish Copper/Nickel/Silver (Cu/Ni/Ag)
Color Yellow (x 4)
Voltage - Rated DC 2.1V
Number of Functions 4
Terminal Pitch 2.54mm
Operating Temperature (Max) 100°C
Operating Temperature (Min) -55°C
Configuration 2 High x 2 Wide
Current 20mA
Viewing Angle 60°
Optoelectronic Device Type SINGLE COLOR LED ARRAY
Forward Current 10mA
Lens Style Round with Domed Top
Lens Size 3mm T-1
Forward Voltage 2.1V
Luminous Intensity 10 mcd
Lens Type Diffused, Tinted
Illumination Color Yellow
Wavelength - Peak 585nm
Lens Color Green
T-code T-1
Dimensions
Height 8.89mm
Length 18.5mm
Width 6.6mm
Compliance
RoHS Status Non-RoHS Compliant
