5690103272F
RoHS
RoHS compliant
RoHS compliantPackage /
Category Optoelectronics / LEDs - Circuit Board Indicators, Arrays, Light Bars, Bar Graphs
Description
LED CBI 3MM BI-LEVEL Y,G,O,G
PDF
/
Inventory: 4682
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Luminous Intensity-Min 0.0034 cd
Number of LEDs 4
Forward Voltage-Max 2.8V
Wavelength - Peak 565nm 600nm 585nm
Millicandela Rating 12.6mcd Green, 7mcd Orange, 10mcd Yellow
Lens Size 3mm T-1
Lens Style Round with Domed Top
Optoelectronic Device Type TRIPLE COLOR LED ARRAY
Viewing Angle 60°
Configuration 2 High x 2 Wide
Subcategory Other Optoelectronics
HTS Code 8541.40.20.00
Voltage - Rated 2.1V Green 2.2V Orange 2.1V Yellow
Color Green (x 2), Orange (x 1), Yellow (x 1)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series 569
Published 2002
Packaging Bulk
Physical
Mounting Type Through Hole, Right Angle
Supply Chain
Factory Lead Time 10 Weeks
