5690102222
RoHS
/
Package /
Category Optoelectronics / LEDs - Circuit Board Indicators, Arrays, Light Bars, Bar Graphs
Description
LED 2X2 3MM HI DENSITY GRN PCMNT
PDF
/
Inventory: 6895
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Through Hole, Right Angle
Surface Mount NO
Mounting Feature RADIAL MOUNT
Technical
Packaging Bulk
Published 2002
Series 569
JESD-609 Code e4
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
Terminal Finish Copper/Nickel/Silver (Cu/Ni/Ag)
Color Green (x 4)
Voltage - Rated 2.1V
HTS Code 8541.40.20.00
Number of Functions 4
Terminal Pitch 2.54mm
Operating Temperature (Max) 100°C
Operating Temperature (Min) -55°C
Configuration 2 High x 2 Wide
Current 20mA
Viewing Angle 60°
Optoelectronic Device Type SINGLE COLOR LED ARRAY
Lens Style Round with Domed Top
Lens Size 3mm T-1
Luminous Intensity 12.6 mcd
Lens Type Diffused, Tinted
Millicandela Rating 12.6mcd
Wavelength - Peak 565nm
Overall Height 8.89mm
T-code T-1
Compliance
RoHS Status Non-RoHS Compliant
