5682231322F
RoHS
RoHS compliant
RoHS compliantPackage /
Category Optoelectronics / LEDs - Circuit Board Indicators, Arrays, Light Bars, Bar Graphs
Description
LED CBI 3MM 4X1 RED,YLW,GRN,GRN
PDF
/
Inventory: 5956
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mounting Type Through Hole, Right Angle
Surface Mount NO
Mounting Feature RADIAL MOUNT
Shape ROUND
Technical
Packaging Bulk
Published 2010
Series 568
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
Color Green (x 2), Red (x 1), Yellow (x 1)
Voltage - Rated 2.1V Green 2V Red 2.1V Yellow
HTS Code 8541.40.20.00
Packing Method BAG
Number of Functions 4
Terminal Pitch 2.54mm
Operating Temperature (Max) 100°C
Operating Temperature (Min) -55°C
Configuration 4 High
Current 30mA Green 30mA Red 20mA Yellow
Viewing Angle 45°
Optoelectronic Device Type TRIPLE COLOR LED ARRAY
Lens Style Rectangle with Flat Top
Lens Size 19.05mmx8.89mm
Luminous Intensity 29.0 mcd
Lens Type Tinted
Millicandela Rating 50mcd Green, 29mcd Red, 30mcd Yellow
Wavelength - Peak 565nm 635nm 585nm
Overall Height 16.51mm
Compliance
RoHS Status ROHS3 Compliant
