56807444444F
RoHS
RoHS compliant
RoHS compliantPackage /
Category Optoelectronics / LEDs - Circuit Board Indicators, Arrays, Light Bars, Bar Graphs
Description
LED Quad-Level Bi-Color Green/Yellow 565nm/585nm Bulk
PDF
/
Buying Options
Total Price: USD $31.7
Unit Price: USD $31.703909
≥1 USD $31.703909
≥160 USD $12.649792
≥480 USD $12.228351
≥960 USD $12.018287
Inventory: 1264
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mounting Type Through Hole, Right Angle
Surface Mount NO
Mounting Feature RADIAL MOUNT
Technical
Packaging Bulk
Published 2008
Series 568
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 32
Terminal Finish Copper/Nickel/Silver (Cu/Ni/Ag)
Color Green, Yellow (x 16)
HTS Code 8541.40.20.00
Number of Functions 16
Terminal Pitch 2.54mm
Operating Temperature (Max) 100°C
Operating Temperature (Min) -55°C
Configuration 4 High x 4 Wide
Viewing Angle 80°
Optoelectronic Device Type DUAL COLOR LED ARRAY
Lens Style Round with Domed Top
Lens Size 3mm T-1
Luminous Intensity 4.3/6.3 mcd
Millicandela Rating 6.3mcd Green, 4.3mcd Yellow
Forward Current-Max 0.03A
Overall Height 21.01mm
T-code T-1
Peak Wavelength 585/565 nm
Compliance
RoHS Status ROHS3 Compliant
