5680102231F
RoHS
RoHS compliant
RoHS compliantPackage /
Category Optoelectronics / LEDs - Circuit Board Indicators, Arrays, Light Bars, Bar Graphs
Description
LED CBI 3MM 4X1 GRN,GRN,YLW,RED
PDF
/
Inventory: 3997
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Luminous Intensity-Min 0.0047 cd
T-code T-1
Number of LEDs 4
Overall Height 20.32mm
Forward Voltage-Max 2.8V
Wavelength - Peak 565nm 635nm 585nm
Millicandela Rating 12.6mcd Green, 10mcd Red, 10mcd Yellow
Luminous Intensity 10.0/12.6 mcd
Lens Size 3.00mm Dia
Lens Style Round with Flat Top
Optoelectronic Device Type TRIPLE COLOR LED ARRAY
Viewing Angle 60°
Current 30mA Green 30mA Red 20mA Yellow
Configuration 4 High
Operating Temperature (Min) -55°C
Operating Temperature (Max) 100°C
Terminal Pitch 2.54mm
Number of Functions 4
Packing Method BAG
Subcategory Other Optoelectronics
HTS Code 8541.40.20.00
Voltage - Rated 2.1V Green 2V Red 2.1V Yellow
Color Green (x 2), Red (x 1), Yellow (x 1)
Terminal Finish Copper/Nickel/Silver (Cu/Ni/Ag)
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e4
Series 568
Published 2009
Packaging Bulk
Physical
Mounting Feature RADIAL MOUNT
Surface Mount NO
Mounting Type Through Hole, Right Angle
Supply Chain
Factory Lead Time 10 Weeks
