5680102200F
RoHS
RoHS compliant
RoHS compliantPackage /
Category Optoelectronics / LEDs - Circuit Board Indicators, Arrays, Light Bars, Bar Graphs
Description
LED CBI 3MM 4X1 GRN,X,X,X
PDF
/
Inventory: 8645
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mounting Type Through Hole, Right Angle
Surface Mount NO
Mounting Feature RADIAL MOUNT
Shape ROUND
Technical
Packaging Bulk
Published 2009
Series 568
JESD-609 Code e4
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 4
Terminal Finish Copper/Nickel/Silver (Cu/Ni/Ag)
Color Green (x 2), Blank (x 2)
Voltage - Rated 2.1V
HTS Code 8541.40.20.00
Subcategory Other Optoelectronics
Packing Method BAG
Number of Functions 2
Terminal Pitch 2.54mm
Operating Temperature (Max) 100°C
Operating Temperature (Min) -55°C
Configuration 4 High
Current 30mA
Viewing Angle 60°
Optoelectronic Device Type SINGLE COLOR LED ARRAY
Lens Style Rectangle with Flat Top
Lens Size 5.00mmx2.50mm
Luminous Intensity 12.6 mcd
Millicandela Rating 12.6mcd
Wavelength - Peak 565nm
Forward Voltage-Max 2.8V
Overall Height 20.32mm
Number of LEDs 4
T-code T-1
Luminous Intensity-Min 0.0047 cd
Compliance
RoHS Status ROHS3 Compliant
