5680102177F
RoHS
RoHS compliant
RoHS compliantPackage /
Category Optoelectronics / LEDs - Circuit Board Indicators, Arrays, Light Bars, Bar Graphs
Description
LED CBI 3MM 4X1 GRN,RED,ORN,ORN
PDF
/
Inventory: 2214
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
T-code T-1
Overall Height 20.32mm
Wavelength - Peak 565nm 600nm 635nm
Millicandela Rating 12.6mcd Green, 7mcd Orange, 10mcd Red
Luminous Intensity 10.0/7.0/12.6 mcd
Lens Size 5.30mmx1.80mm
Lens Style Rectangle with Flat Top
Optoelectronic Device Type TRIPLE COLOR LED ARRAY
Viewing Angle 60°
Current 30mA Green 25mA Orange 30mA Red
Configuration 4 High
Operating Temperature (Min) -55°C
Operating Temperature (Max) 100°C
Terminal Pitch 2.54mm
Number of Functions 4
Packing Method BAG
HTS Code 8541.40.20.00
Voltage - Rated 2.1V Green 2.2V Orange 2V Red
Color Green (x 1), Orange (x 2), Red (x 1)
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series 568
Published 2009
Packaging Bulk
Physical
Shape ROUND
Mounting Feature RADIAL MOUNT
Surface Mount NO
Mounting Type Through Hole, Right Angle
Supply Chain
Factory Lead Time 10 Weeks
