5680101110F

Dialight
RoHS
RoHS RoHS compliant
Package /
Category Optoelectronics / LEDs - Circuit Board Indicators, Arrays, Light Bars, Bar Graphs
Description 568 Rectangle with Flat Top 3 SINGLE COLOR LED ARRAY LED Circuit Board Indicator 2.8V 30mA 10mcd 60°
PDF
/
Inventory: 3404
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Technical

Luminous Intensity-Min 0.0074 cd
T-code T-1
Number of LEDs 4
Overall Height 20.32mm
Forward Voltage-Max 2.8V
Wavelength - Peak 635nm
Millicandela Rating 10mcd
Luminous Intensity 10.0 mcd
Lens Size 8.89mmx3.81mm
Lens Style Rectangle with Flat Top
Optoelectronic Device Type SINGLE COLOR LED ARRAY
Viewing Angle 60°
Current 30mA
Configuration 4 High
Operating Temperature (Min) -55°C
Operating Temperature (Max) 100°C
Terminal Pitch 2.54mm
Number of Functions 3
Packing Method BAG
Subcategory Other Optoelectronics
HTS Code 8541.40.20.00
Voltage - Rated 2V
Color Red (x 3), Blank (x 1)
Terminal Finish Copper/Nickel/Silver (Cu/Ni/Ag)
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e4
Series 568
Published 2009
Packaging Bulk

Physical

Shape ROUND
Mounting Feature RADIAL MOUNT
Surface Mount NO
Mounting Type Through Hole, Right Angle

Supply Chain

Factory Lead Time 10 Weeks
