5640200310F
RoHS
RoHS compliant
RoHS compliantPackage /
Category Optoelectronics / LEDs - Circuit Board Indicators, Arrays, Light Bars, Bar Graphs
Description
LED CBI 3MM 3X1 YLW/RED/X
PDF
/
Inventory: 1400
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mounting Type Through Hole, Right Angle
Surface Mount NO
Mounting Feature RADIAL MOUNT
Technical
Packaging Bulk
Series 564
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 4
Terminal Finish Copper/Nickel/Silver (Cu/Ni/Ag)
Color Red (x 1), Yellow (x 1), Blank (x 1)
Voltage - Rated 1.7V Red 1.8V Yellow
HTS Code 8541.40.20.00
Number of Functions 2
Terminal Pitch 2.54mm
Operating Temperature (Max) 100°C
Operating Temperature (Min) -55°C
Configuration 3 High
Current 7mA Red 30mA Yellow
Viewing Angle 60°
Optoelectronic Device Type DUAL COLOR LED ARRAY
Lens Style Round with Domed Top
Lens Size 3mm T-1
Luminous Intensity 1.6/5.0 mcd
Lens Type Diffused
Millicandela Rating 1.6mcd Red, 5mcd Yellow
Wavelength - Peak 635nm 591nm
Forward Voltage-Max 2.2V
Overall Height 15.24mm
Number of LEDs 2
Luminous Intensity-Min 0.001 cd
Compliance
RoHS Status ROHS3 Compliant
