5640100120F
RoHS
RoHS compliant
RoHS compliantPackage /
Category Optoelectronics / LEDs - Circuit Board Indicators, Arrays, Light Bars, Bar Graphs
Description
LED CBI 3MM 3X1 RED/GRN/X DIFF
PDF
/
Inventory: 2418
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Overall Height 15.24mm
Wavelength - Peak 565nm 635nm
Millicandela Rating 12.6mcd Green, 10mcd Red
Lens Type Diffused
Luminous Intensity 10.0/12.6 mcd
Lens Size 3mm T-1
Lens Style Round with Domed Top
Optoelectronic Device Type DUAL COLOR LED ARRAY
Viewing Angle 60°
Current 30mA Green 30mA Red
Configuration 3 High
Operating Temperature (Min) -55°C
Operating Temperature (Max) 100°C
Terminal Pitch 2.54mm
Number of Functions 2
Packing Method BAG
HTS Code 8541.40.20.00
Voltage - Rated 2.1V Green 2V Red
Color Green (x 1), Red (x 1), Blank (x 1)
Terminal Finish Copper/Nickel/Silver (Cu/Ni/Ag)
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e4
Series 564
Published 2007
Packaging Bulk
Physical
Mounting Feature RADIAL MOUNT
Surface Mount NO
Mounting Type Through Hole, Right Angle
Supply Chain
Factory Lead Time 10 Weeks
