5615701080F
RoHS
RoHS compliant
RoHS compliantPackage /
Category Optoelectronics / LEDs - Circuit Board Indicators, Arrays, Light Bars, Bar Graphs
Description
LED CBI 5MM YLW WATER CLR 0.800"
PDF
/
Inventory: 2237
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mounting Type Through Hole
Surface Mount NO
Mounting Feature RADIAL MOUNT
Shape ROUND
Technical
Packaging Bulk
Series 561
JESD-609 Code e1
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Color Yellow
Voltage - Rated 2.2V
HTS Code 8541.40.20.00
Subcategory Visible LEDs
Number of Functions 1
Terminal Pitch 2.54mm
Operating Temperature (Max) 100°C
Operating Temperature (Min) -55°C
Configuration Single
Current 20mA
Viewing Angle 24°
Size 5mm
Luminous Intensity 140.0 mcd
Lens Type Clear
Millicandela Rating 140mcd
Wavelength - Peak 583nm
Forward Voltage-Max 2.5V
Overall Height 20.3mm
T-code T-1 3/4
Compliance
RoHS Status ROHS3 Compliant
