5615601090F
RoHS
RoHS compliant
RoHS compliantPackage /
Category Optoelectronics / LEDs - Circuit Board Indicators, Arrays, Light Bars, Bar Graphs
Description
561 Round with Domed Top 1 Clear LED Circuit Board Indicator 2.5V 20mA 120mcd 24°
PDF
/
Inventory: 8729
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mounting Type Through Hole
Surface Mount NO
Mounting Feature RADIAL MOUNT
Technical
Packaging Bulk
Published 2002
Series 561
JESD-609 Code e1
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Color Green
Voltage - Rated 2.3V
HTS Code 8541.40.20.00
Subcategory Visible LEDs
Number of Functions 1
Terminal Pitch 2.54mm
Operating Temperature (Max) 100°C
Operating Temperature (Min) -20°C
Configuration Single
Current 20mA
Viewing Angle 24°
Lens Style Round with Domed Top
Lens Size 3mm T-1
Luminous Intensity 120.0 mcd
Lens Type Clear
Millicandela Rating 120mcd
Wavelength - Peak 565nm
Forward Voltage-Max 2.5V
Overall Height 22.9mm
T-code T-1 3/4
Compliance
RoHS Status ROHS3 Compliant
