5554007
RoHS
/
Package /
Category Optoelectronics / LEDs - Circuit Board Indicators, Arrays, Light Bars, Bar Graphs
Description
LED 2MM QUAD 5V RED
PDF
/
Inventory: 9564
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Technical
T-code T-3/4
Overall Height 6.35mm
Wavelength - Peak 650nm
Millicandela Rating 9mcd
Lens Type Clear
Luminous Intensity 0.6 mcd
Lens Size 3mm T-1
Lens Style Round with Domed Top
Optoelectronic Device Type SINGLE COLOR LED ARRAY
Viewing Angle 40°
Current 3mA
Configuration 4 Wide
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Terminal Pitch 2.54mm
Number of Functions 4
HTS Code 8541.40.20.00
Additional Feature HIGH RELIABILITY
Voltage - Rated 5V
Color Red (x 4)
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e1
Series 555
Published 2002
Packaging Bulk
Physical
Mounting Feature RADIAL MOUNT
Surface Mount NO
Mounting Type Through Hole, Right Angle
