5530744205F
RoHS
RoHS compliant
RoHS compliantPackage /
Category Optoelectronics / LEDs - Circuit Board Indicators, Arrays, Light Bars, Bar Graphs
Description
LED CBI 3MM BI-LVL YW/GN YW/GN
PDF
/
Buying Options
Total Price: USD $4.91
Unit Price: USD $4.911443
≥1 USD $4.911443
≥10 USD $4.63344
≥100 USD $4.371176
≥500 USD $4.123741
≥1000 USD $3.890323
Inventory: 1251
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
T-code T-1
Overall Height 10.67mm
Forward Current-Max 0.02A
Wavelength - Peak 565nm 585nm
Millicandela Rating 6.3mcd Green, 4.3mcd Yellow
Luminous Intensity 4.3/6.3 mcd
Lens Size 1.81mm Dia
Lens Style Round with Domed Top
Optoelectronic Device Type DUAL COLOR LED ARRAY
Viewing Angle 80°
Configuration 2 High x 5 Wide
Operating Temperature (Min) -55°C
Operating Temperature (Max) 100°C
Terminal Pitch 2.54mm
Number of Functions 10
HTS Code 8541.40.20.00
Voltage - Rated 2.1V Green 2.1V Yellow
Color Green, Yellow (x 2)
Terminal Finish Copper/Nickel/Silver (Cu/Ni/Ag)
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series 553
Published 2013
Packaging Bulk
Physical
Mounting Feature RADIAL MOUNT
Surface Mount NO
Mounting Type Through Hole, Right Angle
Supply Chain
Factory Lead Time 10 Weeks
