5530133006F
RoHS
RoHS compliant
RoHS compliantPackage /
Category Optoelectronics / LEDs - Circuit Board Indicators, Arrays, Light Bars, Bar Graphs
Description
LED CBI 3MM BI-LVL YELLOW/YELLOW
PDF
/
Buying Options
Total Price: USD $20.62
Unit Price: USD $20.620407
≥1 USD $20.620407
≥209 USD $8.227944
≥494 USD $7.953548
≥1007 USD $7.817007
Inventory: 1139
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mounting Type Through Hole, Right Angle
Surface Mount NO
Mounting Feature RADIAL MOUNT
Technical
Packaging Bulk
Published 2013
Series 553
JESD-609 Code e1
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 24
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Color Yellow (x 12)
Voltage - Rated 2.1V
Additional Feature HIGH RELIABILITY
HTS Code 8541.40.20.00
Number of Functions 12
Terminal Pitch 2.54mm
Operating Temperature (Max) 85°C
Operating Temperature (Min) -25°C
Configuration 2 High x 6 Wide
Current 20mA
Viewing Angle 45°
Optoelectronic Device Type SINGLE COLOR LED ARRAY
Lens Style Round with Domed Top
Lens Size 3mm T-1
Luminous Intensity 6.3 mcd
Lens Type Diffused, Tinted
Millicandela Rating 6.3mcd
Wavelength - Peak 585nm
Overall Height 10.67mm
T-code T-1
Compliance
RoHS Status ROHS3 Compliant
