5530111005F

Dialight
RoHS
RoHS RoHS compliant
Package /
Category Optoelectronics / LEDs - Circuit Board Indicators, Arrays, Light Bars, Bar Graphs
Description LED CBI 3MM BI-LVL RED/RED
PDF
/
Inventory: 3359
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 10 Weeks

Physical

Mounting Type Through Hole, Right Angle
Surface Mount NO
Mounting Feature RADIAL MOUNT

Technical

Packaging Bulk
Published 2013
Series 553
JESD-609 Code e1
T-code T-1
Overall Height 10.67mm
Forward Current-Max 0.02A
Wavelength - Peak 650nm
Millicandela Rating 10mcd
Luminous Intensity 10.0 mcd
Lens Size 3mm T-1
Lens Style Round with Domed Top
Optoelectronic Device Type SINGLE COLOR LED ARRAY
Viewing Angle 45°
Configuration 2 High x 5 Wide
Operating Temperature (Min) -25°C
Operating Temperature (Max) 85°C
Terminal Pitch 2.54mm
Number of Functions 10
HTS Code 8541.40.20.00
Additional Feature HIGH RELIABILITY
Voltage - Rated 2V
Color Red (x 10)
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes

Compliance

RoHS Status ROHS3 Compliant
