5530110F
RoHS
RoHS compliant
RoHS compliantPackage /
Category Optoelectronics / LEDs - Circuit Board Indicators, Arrays, Light Bars, Bar Graphs
Description
553 Round with Domed Top 1 Diffused Tinted LED Circuit Board Indicator 3V 10mA 10mcd 45°
PDF
/
Buying Options
Total Price: USD $1.6
Unit Price: USD $1.6016
≥1 USD $1.6016
≥10 USD $1.0692
≥100 USD $0.8228
≥500 USD $0.639162
≥1000 USD $0.590348
≥3000 USD $0.581055
Inventory: 1077
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Luminous Intensity-Min 0.0036 cd
T-code T-1
Number of LEDs 1
Overall Height 9.65mm
Forward Voltage-Max 3V
Wavelength - Peak 650nm
Millicandela Rating 10mcd
Lens Type Diffused, Tinted
Luminous Intensity 10.0 mcd
Lens Size 3mm T-1
Lens Style Round with Domed Top
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 45°
Current 10mA
Configuration 2 High
Operating Temperature (Min) -25°C
Operating Temperature (Max) 85°C
Terminal Pitch 2.54mm
Number of Functions 1
Packing Method BAG
Subcategory Other Optoelectronics
HTS Code 8541.40.20.00
Additional Feature HIGH RELIABILITY
Voltage - Rated 2V
Color Red (x 1), Blank (x 1)
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e1
Series 553
Published 2008
Packaging Bulk
Physical
Mounting Feature RADIAL MOUNT
Surface Mount NO
Mounting Type Through Hole, Right Angle
Supply Chain
Factory Lead Time 10 Weeks
