5526011200F
RoHS
RoHS compliant
RoHS compliantPackage /
Category Optoelectronics / LEDs - Circuit Board Indicators, Arrays, Light Bars, Bar Graphs
Description
LED CBI 4MM BI-LVL FLAT RED/RED
PDF
/
Inventory: 7082
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Luminous Intensity-Min 0.007 cd
T-code T1-1/2
Overall Height 11.43mm
Forward Voltage-Max 2.2V
Wavelength - Peak 630nm
Millicandela Rating 8.7mcd
Lens Type Diffused, Tinted
Luminous Intensity 8.7 mcd
Lens Size 3mm T-1
Lens Style Round with Domed Top
Optoelectronic Device Type SINGLE COLOR LED ARRAY
Viewing Angle 145°
Current 20mA
Configuration 2 High
Operating Temperature (Min) -55°C
Operating Temperature (Max) 100°C
Reach Compliance Code compliant
Terminal Pitch 2.54mm
Number of Functions 2
Subcategory Other Optoelectronics
HTS Code 8541.40.20.00
Additional Feature HIGH RELIABILITY
Voltage - Rated 2V
Color Red (x 2)
Terminal Finish Copper/Nickel/Silver (Cu/Ni/Ag)
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e4
Series 552
Published 2013
Packaging Bulk
Physical
Shape CYLINDRICAL
Mounting Feature RADIAL MOUNT
Surface Mount NO
Mounting Type Through Hole, Right Angle
Supply Chain
Factory Lead Time 10 Weeks
