5513101F
RoHS
RoHS compliant
RoHS compliantPackage /
Category Optoelectronics / LEDs - Circuit Board Indicators, Arrays, Light Bars, Bar Graphs
Description
LED CBI 3MM DIN YW/GN DIFF RA
PDF
/
Buying Options
Total Price: USD $1.05
Unit Price: USD $1.048985
≥1 USD $1.048985
≥10 USD $1.020887
≥100 USD $0.990767
≥500 USD $0.927547
Inventory: 1166
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
T-code T-1
Overall Height 10mm
Forward Voltage-Max 2V
Wavelength - Peak 565nm 585nm
Millicandela Rating 6.3mcd Green, 4.3mcd Yellow
Lens Type Clear
Luminous Intensity 4.3/6.3 mcd
Lens Size 3mm T-1
Lens Style Round with Domed Top
Optoelectronic Device Type DUAL COLOR LED
Viewing Angle 80°
Current 20mA
Configuration Single
Operating Temperature (Min) -55°C
Operating Temperature (Max) 100°C
Terminal Pitch 2.54mm
Number of Functions 1
Subcategory Visible LEDs
HTS Code 8541.40.20.00
Additional Feature HIGH RELIABILITY
Voltage - Rated 2.1V
Color Green, Yellow
Terminal Finish Copper/Nickel/Silver (Cu/Ni/Ag)
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series 551
Published 1999
Packaging Bulk
Physical
Mounting Feature RADIAL MOUNT
Surface Mount NO
Mounting Type Through Hole, Right Angle
Supply Chain
Factory Lead Time 10 Weeks
