5512503F
RoHS
RoHS compliant
RoHS compliantPackage /
Category Optoelectronics / LEDs - Circuit Board Indicators, Arrays, Light Bars, Bar Graphs
Description
LED CBI 3MM HI EFF ORANGE .250
PDF
/
Inventory: 4627
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mounting Type Through Hole, Right Angle
Surface Mount NO
Mounting Feature RADIAL MOUNT
Technical
Packaging Bulk
Published 2007
Series 551
JESD-609 Code e1
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Color Orange
Voltage - Rated 2.2V
Additional Feature HIGH RELIABILITY
HTS Code 8541.40.20.00
Subcategory Visible LEDs
Number of Functions 1
Terminal Pitch 2.54mm
Operating Temperature (Max) 100°C
Operating Temperature (Min) -55°C
Configuration Single
Current 10mA
Viewing Angle 60°
Lens Style Round with Domed Top
Lens Size 3mm T-1
Luminous Intensity 7.0 mcd
Lens Type Diffused, Tinted
Millicandela Rating 7mcd
Wavelength - Peak 600nm
Forward Voltage-Max 2.2V
Overall Height 8.64mm
T-code T-1
Compliance
RoHS Status ROHS3 Compliant
